Metrolog – 3D Metrology Software
Stock Code:
MTLG-X4
Description
Metrolog X4 is 3D metrology software for dimensional inspection, measurement analysis and quality control. It supports a wide range of measuring equipment, including CMMs, laser trackers, measuring arms, 3D scanners and optical sensors.
Bring measurement data and CAD models into a single inspection workflow. Tools for point cloud processing, geometric dimensioning and tolerancing (GD&T), and customised reporting help teams evaluate part conformity and communicate inspection results.
Key Features
- Multi-device compatibility: Support measurement workflows using compatible CMMs, laser trackers, measuring arms, 3D scanners and optical sensors.
- CAD and measurement data handling: Import and process large CAD files and point clouds, with support for formats including IGES, STEP, CATIA, NX and SOLIDWORKS.
- GD&T analysis: Define and evaluate geometric and dimensional tolerances in accordance with supported ANSI and ISO standards.
- Point cloud processing: Assemble, filter, analyse and extract measurement information from scan data.
- Inspection automation: Automate inspection, analysis and reporting tasks to improve workflow efficiency.
- Customised reporting: Create interactive inspection reports with graphics and annotations.
- Results sharing: Export reports and inspection results in supported formats, including PDF, Excel, Q-DAS and QIF.
Applications
Suitable for dimensional inspection, geometric tolerance verification, scan data analysis and manufacturing quality control across a range of measurement systems.
